Product Summary
The IC697CMM742 is an Ethernet Interface (Type 2) provides high performance TCP/IP communications for the IC697 PLC. The Ethernet Interface (Type 2) plugs into a single slot in an IC697 PLC rack and is configured with the IC641 PLC programming software. Up to four Ethernet Interface (Type 2) modules can be installed in an IC697 PLC CPU rack.
Parametrics
IC697CMM742 absolute maximum ratings: (1)Module Operating Voltage: +5 VDC, +12 VDC (from PLC power supply); (2)Module Current Drain: 2.0 Amps (+5 VDC), typical; 0.5 Amps (+12 VDC), maximum when powering an external AUI transceiver; (3)Module Operating Temperature: 0 to +55℃.
Features
IC697CMM742 features: (1)Connects IC697 PLC to an IEEE 802.3 CSMA/CD 10Mbps Ethernet LAN via one of three network ports: 10BaseT, 10Base2, or AUI; (2)10BaseT and 10Base2 network ports provide direct connection to 10BaseT or 10Base2 network with-out an external transceiver; (3)Standard 15-pin AUI network port allows choice of 10Base5, 10Base2, 10BaseT, 10BaseF, or 10Broad36 medium with user-supplied 802.3-compatible transceiverFirmware is pre-loaded for easy installation and is; (4)maintained indefinitely; firmware is easily upgraded in-system from PC attached to RS-485 serial port.
Diagrams
 |
