MAX8760ETL+T

6-bit VID AMD mobile , PWM, 40-pin 6mm x 6mm thin QFN , 64 CPU core power

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.14~2.26 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.14~2.26

PartNumber:: MAX8760ETL+T

Brand:: Maxim Integrated Products - Maxim | Pack: QFN | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Crystal Xu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-08-20

From Other Seller

Part Number:MAX8760ETL+T
US $2.14 - 2.26
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX8760ETL+T is one member of the MAX8760 family which is designed as the dual-phase, quick-pwm controller for AMD mobile turion 64 CPU core power supplies that can be used in 6-bit VID AMD mobile turion 64 CPU, multiphase CPU core supply. When any of these protection features detect a fault, the controller shuts down.

Parametrics

MAX8760ETL+T absolute maximum ratings: (1)lead temperature (soldering, 10s): +300℃;(2)storage temperature range: -65℃ to +150℃;(3)junction temperature: +150℃;(4)operating temperature range: -40℃ to +100℃;(5)continuous power dissipation (TA=+70℃) 40-pin 6mm x 6mm thin QFN (derate 23.2mW/℃ above +70℃): 1.860 W;(6)REF short-circuit duration: continuous;(7)GND to PGND: -0.3V to +0.3V;(8)LXS to BSTS: -6V to +0.3V;(9)DHS to LXS: -0.3V to (VBSTS+0.3V);(10)LXM to BSTM: -6V to +0.3V.

Features

MAX8760ETL+T features: (1)dual-phase, quick-PWM controller; (2)+/-0.75% VOUT accuracy over line, load, and temperature (1.3V); (3)active voltage positioning with adjustable gain and offset; (4)6-bit on-board DAC: 0.375V to 1.55V output adjust range; (5)selectable 100kHz/200kHz/300kHz/550kHz switching frequency; (6)4V to 28V battery input voltage range; (7)adjustable slew-rate control; (8)drives large synchronous rectifier MOSFETs; (9)undervoltage and thermal-fault protection; (10)power sequencing and timing; (11)selectable suspend voltage; (12)soft-start and soft-shutdown; (13)selectable single- or dual-phase pulse skipping.
