Product Summary
The TAR5S40U is comprised of general-purpose bipolar single-power-supply devices incorporating a control pin which can be used to turn them ON/OFF. Overtemperature and overcurrent protection circuits are built in to the TAR5S40U output circuit.
Parametrics
TAR5S40U absolute maximum ratings: (1)Supply Voltage, VIN: 15V; (2)Output Current, IOUT: 200mA; (3)Power Dissipation, PD: 450mW; (4)Operation Temp. Range, Topr: -40 to 85℃; (5)Storage Temp. Range, Tstg: -55 to 150℃.
Features
TAR5S40U features: (1)Low stand-by current; (2)Overtemperature/overcurrent protection; (3)Operation voltage range is wide; (4)Maximum output current is high; (5)Difference between input voltage and output voltage is low; (6)Small package. (UFV package: Similar toSOT-353); (7)Ceramic capacitors can be used.
