Product Summary
The C707-10M0065122 is a SIM Reader With Integrated Cover Wider Solder Tails.
Parametrics
C707-10M0065122 absolute maximum ratings: (1)Pin: Copper alloy; (2)Insulator: High temperature thermoplastic; (3)Contact area: 0.8 μm Au at mating area; (4)Solder area: 4 μm Sn at solder tail; (5)Under layer: 2 μm Ni under plated; (6)Contact resistance: 100 mOhm max; (7)Voltage rating (SELV):15 Vdc max; (8)Current rating: 1 A; (9)Dielectric strength: 500 Vrms min, 1 min; (10)Insulation resistance: 10E9 Ohm min; (11)Operation temperature: -40℃ to +85℃; (12)Contact force, nominal: 30-70 cN; (13)Mechanical lifetime: 1,500 mating cycles min; (14)Contact position acc. to GSM; (15)Type: tape & reel, Quantity/packaging unit: 650 pcs, 24 mm pitch.
Features
C707-10M0065122 features: (1)Small overall dimension; (2)Secure card position; (3)Reliable contact of SIM-Card pads; (4)Easy and safe locking; (5)Used by major phone manufacturers.
Diagrams
 |
